The Power of Three:

ACL USA is now a Silitronics Company

A "World Class" supplier of semiconductor package substrates and high density interconnects

About Us

A Complete Packaging Ecosystem

Our Company Mission

Advanced Component Labs, located in Santa Clara, California, is the USA's leading fabricator of Semiconductor Package Substrates and High Density Interconnects. With a sharp focus directed towards the semiconductor community

Read More

ITAR Approved USA Fabricator

Quick Turn and Pre-production Manufacturing

High Layer Count Substrates & HDI

Our Products

Ball Grid Arrays

Ball Grid Array substrates are designed for reliable, high-I/O semiconductor packaging where electrical performance, routing density, and manufacturability all matter.

Learn More

Chip Scale Packages

Chip Scale Package substrates help designers reduce footprint while maintaining strong electrical and thermal performance in compact devices.

Learn More

Flip Chips

Flip chip substrates are built for high-density interconnection, short signal paths, and improved electrical performance in advanced semiconductor packages.

Learn More

High Density Interposers

High density interposers provide the fine-pitch routing needed to connect complex devices in advanced packaging architectures.

Learn More
Capabilities

Built for Advanced Substrate Requirements

From controlled dielectric builds to fine line geometry, mechanical analysis, electrical test and laboratory verification, our capabilities support demanding semiconductor package substrate programs.

Laminates & Constructions

High Tg materials, controlled impedance, microstrip, stripline, build ups and RF substrates.

Drilling & Surface Finishes

Mechanical, laser and plasma drilling with wirebondable structures and selective gold finishes.

Mechanical & Test

COC's, cross sections, XRF analysis, high density flying probes, AOI and net list comparison.

Contact Us

End-to-end advanced semi-conductor and silicon photonics packaging services.
